Esp32sim is a Rust emulator that runs ESP32-S3, ESP32-C3 and ESP32-C6 firmware, including in a browser through WebAssembly. Its author says the chips can boot their ROM, bootloader and unmodified applications; reported hardware comparisons show close but not perfect output matches, and the project labels the S3 mature while the C3 and C6 remain drafts.
The Esp32sim project offers a browser-based emulator for firmware on three Espressif microcontrollers: the ESP32-S3, ESP32-C3 and ESP32-C6. Its GitHub documentation says the Rust emulator can run unmodified application images after booting each chip’s ROM and second-stage bootloader, giving developers a way to test some embedded projects without first installing the emulator or connecting a physical board.
The project runs in the browser using WebAssembly, and the repository links to a demo that includes example applications. A local command-line interface is also available. The project says it requires no cloud service or account and is licensed under the MIT license. Its support spans two processor families: Xtensa for the ESP32-S3 and RISC-V for the C3 and C6.
According to the repository, the emulator models enough of each system-on-chip to run real projects through the ROM, bootloader, FreeRTOS and application stages. The S3 version includes a block interpreter and an AArch64 just-in-time compiler; the C3 and C6 versions currently use interpreters without a block cache or JIT. The project reports S3 interpreter/JIT performance of about 150–240 million instructions per second; it says the C3 and C6 can run a hello-world example faster than real time.
Support differs by chip and board. The S3 has display, camera, audio and other peripheral models, while the C3 is described as console-only. The C6 has a modeled ST7789 display on a supported board, along with a stand-in for 802.15.4 energy detection. The project also describes a virtual Wi-Fi access point and network services, with features varying across chips. These are emulator models, not evidence that every peripheral or radio behavior matches physical hardware.
A Browser Test Bench for ESP32 Firmware
Running firmware in a browser can lower the setup cost for trying examples, reproducing bugs and learning embedded development. A developer can open the demo without obtaining a board or building the Rust project first. For teams working across several ESP32 variants, a shared emulator may also help check software behavior before testing on target hardware.
The practical reach depends on what the emulator models. Peripheral behavior, timing, radio features and board-specific wiring can affect whether a project works as expected. Esp32sim is best understood as an additional development and testing tool, not a general replacement for physical-board validation. Hardware-dependent behavior still needs to be checked on the actual device.
As an affiliate, we earn on qualifying purchases.
Esp32sim uses separate CPU implementations for Xtensa and RISC-V, while the repository says the C3 and C6 reuse several peripheral models developed for the S3 where the underlying IP is shared. Each chip still has its own memory map and chip-specific components, including interrupt and cache structures. This design lets the project share some modeled devices without treating the three SoCs as identical.
The repository lists the ESP32-S3 as mature and the C3 and C6 as drafts, with separate documentation for the latter two. It also describes several forms of testing, including decoder checks, golden-output regression tests and comparisons with captured hardware output. Those checks have different scopes: some full-listing and hardware comparison counts come from earlier manual runs and are not run in continuous integration.
“Each boots the real mask ROM, the real 2nd-stage bootloader and an unmodified application image.”
— Esp32sim GitHub repository
As an affiliate, we earn on qualifying purchases.
Hardware Coverage and Test Limits
The repository reports hardware comparisons, but these do not establish exact equivalence across all software or operating conditions. For the C3 and C6, its listed console comparisons found 205 of 208 lines and 203 of 204 lines identical, respectively. For the S3, a JTAG comparison covered 8,000 steps after timing-loop resynchronization. The documentation says the comparison normalizes window exceptions and resynchronizes delay loops, so it is not uninterrupted cycle-by-cycle agreement.
The repository also states that full-listing decoder checks and those hardware counts describe earlier manual runs; CI instead runs checked-in sampled decoder corpora and emulator golden outputs, excluding external full-listing tests. It remains unclear from the supplied material how broadly the browser demo has been tested with third-party firmware, how complete each peripheral model is, or how often the project will update as chip support changes.
As an affiliate, we earn on qualifying purchases.
Further Tests Will Define Its Reach
Users can try the linked browser demo or build the command-line tools and run supported firmware examples. The repository provides chip-specific documentation, example projects and test-scope notes that can help users identify current limitations. Future releases and test updates will show whether the C3 and C6 move beyond draft status and whether support expands to more firmware and board configurations.
For now, developers evaluating the emulator should compare its output with their own target hardware, especially when an application depends on timing, radio behavior or specialized peripherals. The project’s published checks provide useful evidence of progress, but the available material does not establish compatibility with every ESP32 application.
As an affiliate, we earn on qualifying purchases.
Key Questions
Which ESP32 chips does Esp32sim support?
The repository describes support for the ESP32-S3, ESP32-C3 and ESP32-C6, using Xtensa emulation for the S3 and RISC-V emulation for the C3 and C6. It also mentions the classic ESP32’s ECO3 ROM and dual LX6 cores.
Can I try Esp32sim without installing software?
Yes. The project links to a browser demo running through WebAssembly. A command-line version is also available for local use.
Does the emulator run unmodified firmware?
The repository says its supported chips boot their ROM, second-stage bootloader and unmodified application images. That is the project’s stated capability; compatibility can depend on the firmware and the modeled hardware it uses.
Does Esp32sim replace testing on a physical board?
No such guarantee is established in the supplied project material. Its reported hardware comparisons have stated limits, and modeled peripherals or timing may differ from real devices. Developers should still validate hardware-dependent behavior on a physical ESP32 board.
